Toa DP-0206 Operating Instructions

43
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
DP-0206 mounting screw ........................... 2
Terminal block type connector ................... 2
I/O number seal .......................................... 2
* 0 dB = 0.775 V
[Analog Input Module DQ-A01/Analog Output Module DQ-A02] (optional product)
2 channels, +4 dB* (Max. +24 dB*),
10 kΩ, electronically-balanced,
terminal block type connector (4 poles)
–
–
2 channels, +4 dB* (Max. +24 dB*),
adaptable load of over 600 Ω,
electronically-balanced,
terminal block type connector (3 poles)
24 bits
–
24 bits –
DQ-A01 DQ-A02
20 – 20,000 Hz (±1 dB)
110 dB (IHF-A weighted)
48 kHz
Less than 0.05%, 1 kHz, +4 dB* input/output (20 – 20,000 Hz, BPF)
Pre-coated steel plate, black, 30% glossy
25.6 (w) x 76.5 (h) x 168 (d) mm
80 g 100 g
Output
Input
A/D Converter
D/A Converter
Sampling Frequency
Model No.
Frequency Response
Dynamic Range
Total Harmonic Distortion
Finish
Dimensions
Weight
Notes
•
Windows 95/98/NT are Microsoft Corporation's trademarks.
• The design and specifications are subject to change without notice for improvement.
• Accessories
Power cord ................................................. 1
Fuse ........................................................... 1
Rack mounting screw ................................. 4
Finish Panel: Aluminum, hair-line finish, black
Other sections: Pre-coated steel plate, black, 30% glossy
Dimensions
Weight
482 (w) x 88.4 (h) x 331.1 (d) mm
4.65 kg
* 0 dB = 0.775 V

Toa DP-0206 Specifications

General

Brand	Toa
Model	DP-0206
Category	Processor
Language	English
