 Measurement delay time (a time starting from the measurement start-up to the
measurement beginning)
 time showing measurement result
Three measurement speeds are available: FAST (fast, approx. 50meas/ sec), MED (medium,
approx. 10meas/ sec) and SLOW (slow, approx. 6.25meas/ sec).
Operation procedures are as follows:
The measurement result is displayed as a 5-digit number in the decimal point floating mode.
The impedance parameter is displayed in the fixed decimal point mode, while the inductance
parameter is displayed in the floating decimal point mode.
1) Move the cursor to the SPEED zone, the following items will be displayed in the soft key
zone.
 FAST (fast)
 MED (medium)
 SLOW (slow)
3.1.4 File Manage
1）INTER File
2）EXTER File
3.1.5 TOOLS
Operation procedures are as below:
Move to the TOOL zone, the following menus will be displayed in the soft key zone.
 REL OFF (Relative function on /off. When OFF is selected, Relative function will be
disabled; when ON is selected, Relative function will be enabled.)
 SHORT OFF (Choosing OFF to turn off the short function, while choosing ON to
turn it on.)
 SHORT (Execute the short operation)
 DISP ON (Display the measure result on full screen mode. Press any key (except
TRIGGER) to exit.)
 Start Save/ Stop Save: the current measurement result will be saved to a U disk.
Before a U disk is inserted, the save function is disabled.
N
N
N
O
O
O
T
T
T
E
E
E
:
:
:
Measurement speed: when the measurement speed is selected as SLOW or MED, the
measurement result will be a 5-digit number, while in FAST speed it is a 4-digit
number.
Save operation: Be sure to press “Stop Save” to stop saving data after “Start Save” is
pressed, otherwise data will lose.
