TH2523 Series Operation Manual Ver1.2
4
Chapter 2 Introduction to Front Panel and
Operation
This chapter will deal with basic operation procedures of TH2523. Before using the instrument,
please read this chapter carefully.
2.1 Introduction to Front Panel
Figure 2-1 shows the front panel of TH2523.
！
CATⅠ
±300VDC
Max
LCUR LPOT HPOT HCUR
UNKNOWN
PASS
FAIL
LOCK
7
4
1
9
6
3
8
5
2
COPY
RESET
TRIG
SETUPDISP
MENU
0
.
+/-
ENTRY
1 6
9
2 7
10
83 4 5
11
12131415
TH2523 BATTERY TESTER
Figure 2-1 Front Panel
(1) Trademark and Model
Show instrument trademark and model.
(2) [DISP] Key
Press [DISP] to enter into the MEAS DISP page.
(3) [SETUP] Key
