TH2523 Series Operation Manual Ver1.2
35
BUS: Send the measurement result to an upper computer through the
communication interface and the instrument will not display the result.
5.1.6 Average
Range from 1 to 255, programmable
5.1.7 Display Digits
SLOW, MED
FAST
Resistance range
5 digits, maximum display
number: 35,000
4 digits, maximum display
number: 3500
Voltage range
5 digits, maximum display
number: 31,000
4 digits, maximum display
number: 3100
5.2 Test Signal
5.2.1 Frequency
The test signal is a sinusoidal wave with the frequency of 1kHz±0.2Hz.
5.2.2 Maximum Input Voltage
TH2523: The maximum input voltage that the test terminal can withstand is 65V.
TH2523A: The maximum input voltage that the test terminal can withstand is 350V.
5.2.3 Maximum Display Range
Parameter
Measurement Display Range
L
0.2000nH to 1H
R、X、Z
0.001mΩ to 3.5000kΩ
Q
0.001 to 9999.9
θ
Deg -179.99° to 179.99°
Rad -3.1416 to 3.1416
V (TH2523/A)
0.0001V to 350.000V (TH2523A)
