TH2523 Series Operation Manual Ver1.2
20
Introduction to <BIN SETUP>
 MODE：Move the cursor to it, % and ABS will be displayed in the soft key zone.
When % is selected, upper and lower limits will be displayed in the percentage error
mode; When ABS is selected, upper and lower limits will be displayed in the
absolute value error mode.
 COMP：COMP_A and COMP_B for primary and secondary parameters. COMP_A
(ON: the bin comparison function of primary parameter will be enabled; OFF: the
bin comparison function of primary parameter will be disabled) and COMP_B (ON:
the bin comparison function of secondary parameter will be enabled; OFF: the bin
comparison function of secondary parameter will be disabled).
 NOM_A /NOM_B：Nominal value is only valid in % mode. Nominal value for
primary and secondary parameters (NOM_A and NOM_B). You can input nominal
values of primary and secondary parameters through the numerical keyboard.
 HIGH_A/LOW_A：High and low limit for primary and secondary parameters.
According to different modes, the value of high and low limit can be respectively
percentage value (-100~100) and absolute value (-10000~10000).
 CLEAR: Press it in soft key area and the setup data on where the cursor is located
can be cleared.
 CLEAR LINE: Press it in soft key area and the line setup data in which the cursor
is positioned can be cleared.
3.6 <TRACE SETUP>
Press SETUP key and then press TRACE SETUP to enter into the <TRACE SETUP>
page shown as figure 3-7.
