TH2523 Series Operation Manual Ver1.2
30
4.2.1 Introduction to Save/Recall
By the function of save/recall, user can save measurement results and configuration
information to TH2523 internal Flash or external U disk; meanwhile user can recall data from
TH2523 internal Flash or external U disk.
Introduction to Methods and Applications of Save
The table below shows the applicable save methods and applications:
Table 4-1 Methods and Applications of Save
save method
recall
application
type
file format
configuration save
(internal Flash)
*.STA
Yes
Save the current configuration to
internal Flash.
configuration save
(external U disk)
*.STA
Yes
Save the current configuration to a U
disk.
data save (external U
disk)
*.CSV
No
Save measurement results to a U
disk.
screen save (external U
disk)
No
Save the screen information to a U
disk.
4.2.2 Structure of File Folder/ File in a U Disk
Before saving data to a U disk, you are recommended to save it into a file and folder that have
existed in the memory as shown in table 4-2. If you want to save the configuration file into a
file folder in PC, you should enter into the folder on the instrument and then take relative file
operations.
Table 4-2 Folder in U disk
Folder
Maximum Amount of File
Description
CSV
102
Including measurement result, like *.CSV file.
STA
102
Including configuration data, like *.STA file.
PIC
102
Including screen information, like *.GIF file.
NOTE: CSV and STA folders might be automatically generated when a U disk is connected.
Structure of Folder/File in a U disk is shown in figure 4-2.
