TH2523 Series Operation Manual Ver1.2
28
ENGLISH: Set the language as English.
CHINESE: Set the language as Chinese.
4.1.3 Password
Set the password protection function.
OFF: Disable the password protection function. Before turning off the password protection
function, you must input the original password.
ON: Enable the password protection function. The passwords are used to start up the
instrument and to protect files.
MODIFY: This key is used to modify password.
————————————————————————
NOTE: The default password is 2523.
————————————————————————
4.1.4 Bus Mode
Set the communication interface.
Operation Procedures:
1) Move the cursor to Bus Mode, the following items will be displayed.
RS232C
GPIB (option)
USBTMC
USBCDC
2) Press RS232C, the RS232C interface is selected.
3) Press GPIB, the GPIB interface is selected.
——————————————————————————————————
NOTE: GPIB is an option. Only when it is installed, this mode can be available.
——————————————————————————————————
4) Press USBTMC, the USBTMC interface is selected. The instrument communicates
with PC through the USB interface (USB DEVICE) on the rear panel.
5) Press USBCDC, the USBCDC interface will be selected. The instrument
communicates with PC through USB (USB DEVICE) virtual serial interface.
4.1.5 Baud Rate
Baud rate is used to select the baud rate for RS232 interface. There are 6 selectable baud rates:
9600, 19200, 28800, 38400, 57600, 115200.
Move the cursor to Baud Rate, the following items will be displayed in soft key area.
INCR+: Touch this key to increase the baud rate.
DECR-: Touch this key to decrease the baud rate.
