Topcon GPT-7502 User Manual

11
1 NOMENCLATURE AND FUNCTIONS
Telescope focusing knob
Telescope grip
Telescope eyepiece
Plate level
Circular level
Instrument
height mark
Battery cover
Adjusting screw
for circular level
Power switch
Stylus pen
Battery cover lever
Operation keys
Display window
(With touch panel)
Cover sensor
(Inside the cover)
Power supply connector
Serial Signal Connector
Vertical motion clamp *1)
Vertical tangent screw
2speed way:
GPT-7501/7502/7503
GTS-751/752/753
1speed way:
GPT-7505
GTS-755
*1) The position of vertical motion clamp and tangent screw will differ depend on the markets.
Horizontal
motion clamp
Horizontal
tangent screw
2speed way:
GPT-7501/7502/7503
GTS-751/752/753
1speed way:
GPT-7505
GTS-755
