1 NOMENCLATURE AND FUNCTIONS
1 NOMENCLATURE AND FUNCTIONS
1.1 Nomenclature
Objective lens
Instrument
center mark
Optical plummet
telescope
Leveling screw
Base
Handle fixing screw
Sighting collimator
Carrying handle
Laser pointer
Laser aperture
Card cover lever
Card cover
Hardware reset switch
(Inside the cover)
Tribrach fixing lever
USB connector
Point guide
Stylus pen
Operation keys
Display window
(With touch panel)
Only for GPT-7500
The GTS-755 and GPT-7505 are one-display models.
