33
PREPARATIONS
CONNECTING THE EXTERNAL I/O TERMINALS
DATA OUTPUT
This product can be connected to a personal computer (PC) and other external devices via LAN.
1 Remove the terminal cover by pulling up as follows.
2 Insert the connection cable (LAN cable) into the terminal of the instrument.
3 Connect the other end of the connection cable (LAN cable) to the PC, etc.
CAUTIONS
To avoid electric shock, do not touch the external connection terminal
and the patient at the same time.
NOTES
Use the external device conforming to IEC60950/IEC60950-1.
For connecting to an external device, contact your TOPCON dealer or the
offices listed on the back cover.
