Chapter 1
10
UM10349_PCNC1100_Manual_0916A
Preface
4. Operaon 38
4.1 Control Locaons 38
4.1.1 Operator Panel 38
4.1.2  PathPilot Interface 38
4.2 Inializing the Mill 39
4.2.1 Vital Reference 39
4.3 Jogging 39
4.3.1 Manual Control Group 39
4.4 Spindle Controls 40
4.4.1 Manual Spindle Control Via Operator Panel 40
4.4.2 Automated Spindle Control Via PathPilot Interface 41
4.4.3 Changing Spindle Speed Range 41
4.5 Tool Holders 42
4.6 Part Setup/Workholding 43
5. Intro to PathPilot 44
5.1 Making Your First Part 44
5.1.1 Referencing the Mill 44
5.1.2 Workpiece Preparaon 45
5.1.3 Tooling Preparaon 45
5.1.4 Mill Posion, Work Osets and Tool Osets 45
5.1.4.1 Seng Work Oset by Touching O Workpiece 46
5.1.4.2 Seng Tool Length Oset by Touching O Workpiece 48
5.1.5 Wring the G-code 49
5.1.5.1 Operaon 1 49
5.1.5.2 Operaon 2 51
6. PathPilot Interface 53
6.1 Overall Layout 53
6.2 Persistent Controls 54
