Tormach PCNC 1100 User Manual

Chapter 1
11
UM10349_PCNC1100_Manual_0916A
Preface
6.2.1 Program Control Group 54
6.2.2 Posion Status Group 56
6.2.3 Manual Control Group 57
6.2.4 Keyboard Shortcuts 60
6.3 Main Tab 60
6.4 File Tab 64
6.5 Sengs Tab 65
6.6 Osets Tab 68
6.6.1 Tool Tab 68
6.6.1.1 Oine Measurement with Height Gauge 69
6.6.1.2 Automated Measurement with an Electronic Tool Seer 69
6.6.1.3 Measurement by Touching O Tool 70
6.6.2 Osets Table 70
6.6.3 Tool Oset and Fixture Informaon Backup 70
6.6.4 Work Tab 70
6.7 Conversaonal Tab 71
6.7.1 Face Tab 71
6.7.2 Prole Tab 72
6.7.3 Pocket Tab 73
6.7.3.1 Rectangular 73
6.7.3.2 Circular 75
6.7.4 Drill/Tap Tab 76
6.7.4.1 Drill 78
6.7.4.2 Tap 79
6.7.5 Thread Mill Tab 80
6.7.6 Engrave Tab 82
6.8 Probe Tab 84

Tormach PCNC 1100 Specifications

General

Spindle Speed	100 - 5140 RPM
Spindle Taper	R8
Machine Type	CNC Mill
X Travel	18.0 in (457 mm)
Y Travel	9.5 inches
Z Travel	16.25 inches
Spindle Motor	1.5 hp
Voltage	220 VAC, Single Phase
Table Size	34.0 in x 9.5 in (864 mm x 241 mm)
