Chapter 6

UM10349_PCNC1100_Manual_0916A

PathPilot Interface

6.4 File Tab

The File tab screen is used to transfer les to and from a USB drive, copy, delete, and rename les

and folders (see Figure 6.14). The le window shows les and folders on the controller hard drive;

the middle window shows les and folders on a removable USB drive. The controller does not run

programs from the USB drive – programs must be copied to the controller before loaded and run.

The Back buon and either Home or USB buons above the le and middle window can be used to

navigate through the le structure, which is similar to the le structure on a home computer (see

Figure 6.14). The Copy to USB and Copy From USB arrow buons between the hard drive and USB

drive windows are used to move les between the USB drive and the controller (see Figure 6.14).

Transfer Files or Folders from USB Drive to Controller

1. Insert a USB drive into USB port.

2. Navigate to the le to copy by double clicking on folders in the USB Drive Window.

NOTE: Use the Back buon to navigate backwards or the USB buon to jump to the highest (home) level

(see Figure 6.12).

3. In the Hard Drive Window, navigate to the desired folder/locaon in the PathPilot interface.

4. Highlight the le or folder to copy in the USB Drive Window; click Copy From USB buon (see

Figure 6.14).

5. If the le to be transferred has the same name as an exisng le on the controller, you can

either overwrite the le, give it a dierent name, or cancel the le transfer.

Figure 6.14

Hard Drive Window

USB Drive Window
