Tormach PCNC 1100 User Manual

Chapter 8
152
UM10349_PCNC1100_Manual_0916A
Accessories
8.7.2 Switchable Convenience Outlet Kit
Adds an addional switched outlet for low-current devices. Recommended for toggling mill between
ood coolant and mist coolant.
PN Description
33043 Switchable Convenience Outlet
NOTE: Can be used in conjuncon with External Contactor Kit to interface devices with currents exceeding 1 A.
8.7.3 USB M-code I/O Interface Kit
This device allows the user to assign custom M-code commands to three opcally isolated inputs
and four relay contact outputs. This is useful for integrang a beacon light, auto part loader, or
pneumac vise via program command.
PN Description
32616 USB M-code I/O Interface Module
8.7.4 Integrated Remote E-stop Kit
Adds an addional E-stop buon to any mill. Mulple Remote E-stop Kits can be linked together in
series to provide mulple stop locaons.
PN Description
30790 Integrated Remote E-stop Kit
30785 E-stop Interface Kit
NOTE: Each PCNC mill requires one Remote E-stop Interface. Mulple E-stops can share a single interface.
8.8 Controller Options
8.8.1 USB Bulkhead Port Assembly
Provides a convenient USB port on any PCNC mill stand to load programs into any PCNC mill controller
without the need to open the controller cabinet.
PN Description
31289 USB Bulkhead Port Assembly

Tormach PCNC 1100 Specifications

General

Spindle Speed	100 - 5140 RPM
Spindle Taper	R8
Machine Type	CNC Mill
X Travel	18.0 in (457 mm)
Y Travel	9.5 inches
Z Travel	16.25 inches
Spindle Motor	1.5 hp
Voltage	220 VAC, Single Phase
Table Size	34.0 in x 9.5 in (864 mm x 241 mm)
