Tormach PCNC 1100 - Calibrating Probe Tip

Chapter 8
155
UM10349_PCNC1100_Manual_0916A
Accessories
Seng Probe/Tool Seer Polarity
1. Click on the Sengs tab (see Figure 8.20).
2. Select the appropriate opon from the two probe types.
8.9.3.1 Calibrating Probe Tip
For best results, the probe must be rounely calibrated so the center line of the probe p is coaxial
to the centerline of the PCNC mill spindle. The calibraon procedure should be done:
• Prior to rst use
• Aer p replacement
• Periodically aer extended usage
NOTE: The probe has three adjustment set screws 120° apart (see Figure 8.21 and Figure 8.22).
Calibrate the probe as follows (see Figure 8.23):
1. Choose the Probe tab, then choose Probe/ETS Setup tab.
2. Refer to the Probe Tip Adjustment screen instrucons as shown in Figure 8.23.
Figure 8.21
(C not visible)
A
B
Digitizing Probe Set Screws
Figure 8.22
B
A
C
Passive Probe Set Screws
