Tormach PCNC 1100 - Ribbon Cable and Miscellaneous

Chapter 11
228
UM10349_PCNC1100_Manual_0916A
Diagrams and Parts List
11.7 Ribbon Cable and Miscellaneous
IDC-26 30168
CABLE-26 30170
DB25 MALE 30166
IDC-16 30167 (2)
CABLE-16 30169
I/O MOUNT PLATE - 30210
OUTLET COOLANT (PN 30177)
OUTLET COMPUTER (PN 30177)
4 empty
2 wires not connected
26 Pin IDC Connector
IDC-26 30168
CABLE-26 30170
DB25 MALE 30166
IDC-16 30167 (2)
CABLE-16 30169
I/O MOUNT PLATE - 30210
OUTLET COOLANT (PN 30177)
2 wires not connected
26 Pin IDC Connector
IDC-26 30168
CABLE-26 30170
DB25 MALE 30166
IDC-16 30167 (2)
CABLE-16 30169
I/O MOUNT PLATE - 30210
OUTLET COOLANT (PN 30177)
2 wires not connected
X-Axis
26 Pin IDC Connector
30686
J6 - STEPPER DRIVERS
30684
J4 - DB25 MALE
IDC-26 30168
CABLE-26 30170
DB25 MALE 30166
IDC-16 30167 (2)
CABLE-16 30169
30685
J3 - CONNECTION BOARD
PIN 1 is next to the triangle
TRIANGLE
Example IDC-26, IDC-16 and IDC-10
I/O MOUNT PLATE - 30210
OUTLET COOLANT (PN 30177)
OUTLET COMPUTER (PN 30177)
4-40 STANDOFF (PN 30211)
4-40 NUT (PN 30212)
POWER INLET (PN 30258)
3.5mm
24.6 in
24.6 in
4TH AXIS EXPANSION
On side of cabinet
A-Axis
2 wires not connected
Z-Axis
Y-Axis
26 Pin IDC Connector
PIN 1
E-STOP INTERFACE PORT
On side of cabinet
3.5mm
21.4 in
21.4 in
PIN 2
