Diagrams and Parts List
Tools and Related Items
PN Description
30409 Manual Oil Pump
31374 Automatic Oiler
31386 Machine Way Oil
30485
Spanner Wrench 25-28 mm -DIN 1804 applications, DIN 1810 form A standard. Used for setting preload on
ball screw mount bearings. Two wrenches are needed
31118 Adjustable Pin Spanner. 4 mm pins (for adjusting spindle bearing preload)
30527
Optical laser tachometer 100,000 RPM; ve-digit digital display. Useful for spindle speed calibration; includes case.
35426 Operator Manual: Update to latest version; spiral bound. PDF can also be downloaded at www.tormach.com
30572 Latex Touch-up Paint – Dark Gray 2.5 oz matching lower section of stand (original paint is oil based).
30571
Latex Touch-up Paint – Light Gray 2.5 oz matching upper section of stand (original paint is oil based). Paint
cannot be shipped during cold weather.
NOTE: Valspar Tractor and Implement paint #5339-13 Ford Gray is a close match.
30624 DIN Connector – 5 pin. This is a plug that will t in the accessory jack on the front of the machine cabinet.
30482
CPC Connector – Reverse Gender. This plug is on the end of the 4th axis and connects to the side of the
PCNC cabinet.
30712 Machine Stand Door Latch Left
30713 Machine Stand Door Latch Right
30714 Machine Stand Door Latch Center
30725 Coolant Hose, armored (1/2” NPS-14)
32746 Coolant Pump, 120 VAC
31105 Coolant Hose Mount Bracket
32833 Segmented Spray Hose (blue/orange) 1/4” NPT
31107 Coolant Mounting Coupling (old)
32832 Coolant Mounting Coupling 1/4” NPT (new)
31366 Coolant Refractometer
31101 Spindle Load Meter Top Mounted
32096 Spindle Load Meter Face Mounted
31706 Pneumatic Power Drawbar
31728 Foot Pedal for Power Drawbar
33215 Coolant Accessory Kit
33068 Coolant Adaptor and Hose Upgrade Kit (for those machines equipped with 31107)
