Toro 07253 Service Manual

Workman 1100/2100/2110
Drive Train
Page 5 – 46
1. Cable bracket 2. Bolt (steel ball, spring, & gasket)
Figure 77
12 to 15 ft–lb
(16 to 20 N–m)
2
1
F. Install cable bracket to the transaxle.
G. Install steel ball, spring, gasket, and bolt. Torque
bolt from 12 to 15 ft–lb (16 to 20 N–m).
H. Fill transaxle with 1.5 quarts (1.4 liters) of new
10W–30 motor oil.
