Workman 1
100/2100/21
10
Drive T
rain
Page 5 – 26
1. Ball
bearing
2. Input
shaft
Figure 40
1
2
IMPORT
ANT
:
Do not reuse ball bearings that have
been removed.
B.
Remove ball bearing from the input shaft with a
bearing puller
.
1.
Governor plate assembly
2.
Governor base
Figure 41
1
2
IMPORT
ANT
:
Make sure not to damage the screw
heads when removing screws. Each screw is se-
cured with an adhesive.
C.
Remove screws securing the governor plate as-
sembly to the governor base.
79
81
