Workman 1100/1110/2100/2110 Page 7 -- 15 Chassis, Wheels, and Brakes (Rev. B)
5. Remove four flange lock nuts and carriage screws
securing the steering column to the mounting plate on
the frame.
6. Remove dust cover from the steering shaft. Replace
cover if damaged. Slide steering s haft out of the steering
column.
7. Disconnect both tie rods from the Pitman arm on the
steering gearbox (see Lower Steering and Front Wheel
Removal).
8. Remove flange lock nuts and cap screws securing
the steering gearbox to the tower plate on the front
frame. Remove gearbox from the tower plate.
Installation
1. Position steering gearbox to the tower plate of the
front frame with the Pitman arm facing down and to the
rear. The gearbox shaft must be to the left side of the
tower.
2. Secure steering gearbox to the tower plate with four
cap screws and flange lock nuts.
3. Insert steering shaft up through the s teering column.
Place dust cover onto the shaft.
4. Secure steering column to the mounting plate on the
frame with four carriage screws and flange lock nuts.
NOTE: Apply antiseize lubricant to the steering gear-
box shaft before installing to steering shaft knuckle.
5. Position knuckle of the lower steering shaft onto the
gearbox shaft. Secure knuckle to the steering gearbox
shaft with cap screw and lock washer.
6. Connect both tie rods to the Pitman arm on the steer-
ing gearbox (see Lower Steering and Front Wheel
Installation).
NOTE: Apply antiseize lubricant to the s teering shaft
taper before installing the steering wheel.
7. Position front tires straight ahead. Position steering
wheel to the steering shaft so that the leg of the “Y”
formed by the w heel struts is directed towards the oper-
ator platform.
8. Secure steering w heel to shaft with lock washer and
nut. Torque nut from 13 to 17 ft--lb (18 to 23 N--m). Install
steering wheel cover to wheel.
9. Install front hood to the frame and fenders (see Front
Hood Installation).
10.Check front wheel alignment (see Adjust Front
Wheel Toe--in).
and Brakes
Chassis, Wheels,
Rev. C
