Toro 30605 - Operator Controls Overview

3
CheckingtheTirePressure
NoPartsRequired
Procedure
Checkthetirepressure;refertoCheckingtheTirePressure
(page21).
4
CheckingtheFluidLevels
NoPartsRequired
Procedure
1.Checktheengine-oillevel;refertoCheckingthe
Engine-OilLevel(page41).
2.Checkthehydraulicuidlevel;refertoCheckingthe
HydraulicFluid(page52).
3.Checkthecoolingsystem;refertoCheckingthe
CoolingSystem(page48).
4.Checktheplanetary-gear-driveoil;refertoChecking
thePlanetary-Gear-DriveOil(page45).
5.Checktherear-axlelubricant;refertoCheckingthe
Rear-AxleLubricant(page46).
6.Checktherear-axle-gearboxlubricant;referto
CheckingtheRear-Axle-GearboxLubricant(page47).
ProductOverview
Controls
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
9
10
g020756
Figure3
1.Brakepedals6.Hazard-lightswitch
(optional)
2.Pedal-lockinglatch7.Turn-signalswitch
(optional)
3.Parking-brakelatch
8.Hornbutton(optional)
4.Spaceforoptional
accessory
9.Tractionpedal
5.Beaconswitch(optional)
10.Tilt-steeringlever
TractionPedal
Tostop,reduceyourfootpressureonthetractionpedaland
allowittoreturntothecenterposition(Figure3).
BrakePedals
Thereare2footpedalsthatoperateindividualwheelbrakes
forturningassistance,parking,andtoaidinbetterside-hill
traction.Alatchconnectsthepedalsforparking-brake
operationandtransport(Figure3).
Pedal-LockingLatch
Thepedal-lockinglatchconnectsthepedalstogetherto
engagetheparkingbrake(Figure3).
Tilt-SteeringLever
Pressthetilt-steeringleverdowntotiltthesteeringwheel
tothedesiredposition,thenreleasethelevertolockthe
adjustment(Figure3).
13
