Toro 30605 - Preparing the Machine for Maintenance; Removing the Hood; Lubrication; Greasing the Bearings and Bushings

•Donottouchpartsofthemachineoranattachment
thatmaybehotfromoperation.Allowthepartstocool
beforeattemptingtomaintain,adjust,orservicethem.
•Usejackstandstosupportthemachineand/orits
componentswhenrequired.
•Carefullyreleasepressurefromcomponentswithstored
energy.
•Ifyourmachinerequiresmajorrepairsorifyoudesire
assistance,contactanAuthorizedToroDistributor.
•UseonlygenuineTororeplacementpartsandaccessories.
Replacementpartsandaccessoriesmadebyother
manufacturerscouldbedangerous,andsuchusecould
voidtheproductwarranty.
PreparingtheMachinefor
Maintenance
1.EnsurethatthePTOisdisengaged.
2.Parkthemachineonalevelsurface.
3.Settheparkingbrake.
4.Lowerthemowerdeck(s)ifnecessary.
5.Shutofftheengineandwaitforallmovingpartsto
stop.
6.TurntheignitionkeytotheSTOPpositionandremove
it.
7.Allowmachinecomponentstocoolbeforeperforming
maintenance.
RemovingtheHood
1.Unlatchandraisethehood.
2.Removethehairpincottersecuringthehoodpivotto
themountingbrackets(Figure33).
Figure33
1.Hairpincotter
3.Slidethehoodtotherightside,lifttheotherside,and
pullitoutofthebrackets.
Note:Reversethisproceduretoinstallthehood.
Lubrication
GreasingtheBearingsand
Bushings
ServiceInterval:Every50hours(lubricateafterevery
washing).
Note:Themachinehasgreasettingsthatyoumust
lubricateregularlywithNo.2lithiumgrease.
Thegreasettinglocationsandquantitiesareasfollows:
TractionUnit
•2brakepedalpivot-shaftbearings(Figure34)
•2frontandrear-axle-pivotbushings(Figure35)
•2steering-cylinder-balljoints(Figure36)
•2tie-rod-balljoints(Figure36)
•2king-pinbushings(Figure36).
Note:Lubricateonlythetopttingonthekingpin
annually(2pumps).
Figure34
Figure35
37
