Figure36

FrontMowerDeck

•2caster-fork-shaftbushings(Figure37)

•3spindle-shaftbearings—locatedunderthepulley(Figure

38)

•2idler-arm-pivotbushings(Figure38)

Figure37

g017810

Figure38

FrontLiftAssemblies

•2(eachside)lift-arm-cylinderbushings(Figure39)

•2lift-arm-balljoints(Figure40)

Figure39

Figure40
