LocatingtheFuses
Thetraction-unitfusesarelocatedunderthepower-center
cover(Figure54,Figure55,andFigure56).
Removethe2screwssecuringthepower-centercovertothe
frameandremovethecover(Figure54).
Figure54
1.Power-centercover
2.Screws
Figure55
1.Fuses
Figure56
DriveSystem
Maintenance
AdjustingtheTraction-Pedal
Angle
1.Loosenthe2nutsandboltssecuringtheleftsideofthe
tractionpedaltothebracket(Figure57).
Figure57
1.Tractionpedal2.Mountingnutsandbolts
2.Pivotthepedaltothedesiredoperatingangleand
tightenthenuts(Figure57)˙.
Checkingthe
Planetary-Gear-DriveOil
ServiceInterval:Every400hours(checkifyounotice
externalleakage).
Every400hours
UsehighqualitySAE85W-140gearlubeasareplacement.
1.Withmachineonlevelsurface,positionthewheelso1
checkplugisatthe12o'clockpositionandtheother
isat3o'clockposition(Figure58).
g019500
Figure58
1.Check/drainplug(2)
2.Removetheplugatthe3o’clockposition(Figure58).
