Toro 30605 - Checking the Rear Wheel Toe-In; Cooling System Maintenance; Cooling System Safety; Checking the Cooling System

CheckingtheRearWheel
Toe-In
ServiceInterval:Every800hours
1.Measurethecenter-to-centerdistance(ataxleheight)at
thefrontandrearofthesteeringtires.
Note:Thefrontmeasurementmustbe6mm(1/4
inch)lessthantherearmeasurement.
2.Toadjust,loosentheclampsatbothendsofthetie
rods.
3.Rotatethetie-rodendtomovethefrontofthetire
inwardoroutward.
4.Tightenthetie-rodclampswhentheadjustmentis
correct.
CoolingSystem
Maintenance
CoolingSystemSafety
CAUTION
Dischargeofhot,pressurizedcoolantortouchinga
hotradiatorandsurroundingpartscancausesevere
burns.
•Donotremovetheradiatorcapwhentheengine
ishot.Alwaysallowtheenginetocoolatleast15
minutesoruntiltheradiatorcapiscoolenough
totouchwithoutburningyourhandbefore
removingtheradiatorcap.
•Donottouchtheradiatorandsurroundingparts
thatarehot.
DANGER
Swallowingenginecoolantcancausepoisoning.
•Donotswallowenginecoolant.
•Keepoutofreachfromchildrenandpets.
CheckingtheCoolingSystem
ServiceInterval:Beforeeachuseordaily
Checkthecoolantlevelatthebeginningofeachday.The
capacityofthesystemis8.5L(9USqt).
1.Carefullyremovetheradiatorcapandexpansion-tank
cap(Figure65).
2.Checkthecoolantlevelintheradiator.
Note:Theradiatorshouldbelledtothetopofthe
llerneckandtheexpansiontanklledtotheFull
mark.
Figure65
1.Expansiontank
3.Ifthecoolantislow ,adda50/50mixtureofwaterand
ethyleneglycolanti-freeze.
