CheckingtheTorqueofthe
Wheel-LugNuts
ServiceInterval:Afterthersthour
Aftertherst10hours
Every200hours
Torquethewheel-lugnutsto115to136N∙m(85to100ft-lb)
intheordershowninFigure10andFigure11.
Figure10
FrontWheels
Figure11
RearWheels
WARNING
Failingtomaintainpropertorqueofthewheel-lug
nutscouldresultinpersonalinjury.
Torquethewheel-lugnutstothepropertorque
value.
AdjustingtheRollover
ProtectionSystem(ROPS)
WARNING
Toavoidinjuryordeathfromrollover:keepthe
rollbarintheraisedlockedpositionandusethe
seatbelt.
Ensurethattheseatissecuredwiththeseatlatch.
WARNING
Thereisnorolloverprotectionwhentherollbaris
inthedownposition.
•Donotoperatethemachineonunevenground
oronahillsidewiththerolloverprotectionin
thedownposition.
•Lowertherollbaronlywhenabsolutely
necessary.
•Donotweartheseatbeltwhentherollbaris
inthedownposition.
•Driveslowlyandcarefully.
•Raisetherollbarassoonasclearancepermits.
•Checkcarefullyforoverheadclearances(i.e.,
branches,doorways,electricalwires)before
drivingunderanyobjectsanddonotcontact
them.
Important:Alwaysusetheseatbeltwhentherollbar
isintheraisedandlockedposition.Donotusetheseat
beltwhentherollbarisintheloweredposition.
