16
Set Schedule Type
8FFLEBZ4DIFEVMJOH
Selecting Weekday scheduling will activate all 7 days of the week. You can disable any of the 7 days as a non-watering day.
Step 1 While in the ADVANCED/SCHEDULE DETAILS menu, use the Up
or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 Use the Up
or Down arrows to navigate to TYPE. Press the Right arrow or SELECT .
Step 3 Use the Up
or Down arrows to select WEEKDAY. Press SELECT .
SCHEDULE A
STATUS ENABLED
TYPE
WEEKDAY
RESTRICTIONS
MONTHLY ADJUST
Step 4 Press the BACK arrow to return to the previous menu or HOME to return to the main screen.
0EE%BZ4DIFEVMJOH
Selecting Odd scheduling will activate all odd-numbered days in the calendar as a watering day. e 31st day of the month is not a watering
day.
Step 1 While in the ADVANCED/SCHEDULE DETAILS menu, use the Up
or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 Use the Up
or Down arrows to navigate to TYPE. Press the Right arrow or SELECT .
Step 3 Use the Up
or Down arrows to select ODD. Press SELECT .
SCHEDULE A
STATUS ENABLED
TYPE
ODD
RESTRICTIONS
MONTHLY ADJUST
Step 4 Press the BACK arrow to return to the previous menu or HOME to return to the main screen.
&WFO%BZ4DIFEVMJOH
Selecting Even will activate all even-numbered days in the calendar as a watering day.
Step 1 While in the ADVANCED/SCHEDULE DETAILS menu, use the Up or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 Use the Up
or Down arrows to navigate to TYPE. Press SELECT .
Step 3 Use the Up
or Down arrows to select EVEN. Press the Right arrow or SELECT .
SCHEDULE A
STATUS ENABLED
TYPE
EVEN
RESTRICTIONS
MONTHLY ADJUST
Step 4 Press the BACK arrow to return to the previous menu or HOME to return to the main screen.

Other manuals for Toro EVOLUTION Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toro EVOLUTION Series and is the answer not in the manual?

Toro EVOLUTION Series Specifications

General IconGeneral
Weather Sensor CompatibilityYes
Output Voltage24 VAC
DisplayLCD
Wi-Fi ConnectivityYes (with optional Wi-Fi module)
MountingIndoor/Outdoor
Maximum Load Current0.5 amps per station
Operating Temperature-40°C to 60°C
Enclosure RatingNEMA 3R
WeightVaries by model
Zones4 to 16 (in modules of 4)
