Toro EVOLUTION Series User Manual

22
Help/Setup
Alerts
e EVOLUTION
TM
controller always checks the system for proper function and it will provide feedback if it detects any system
abnormality. e Alerts menu allows you to view and clear detected system faults.
Alert Listings
Short - EVOLUTION
TM
detected a short in the zone.
0WFSDVSSFOU - EVOLUTION
TM
detected an over current in the zone. Over current occurs when a terminal exceeded the recommended
current rating.
-PX#BUUFSZ - EVOLUTION
TM
detected no battery installed or the battery’s power is low. Once the Low Battery alert is cleared, it will not
display again unless a Factory Reset is performed.
-PX"$1PXFS - EVOLUTION
TM
detected low or no A/C power.
'BDUPSZ3FTFU - EVOLUTION
TM
encountered an error that required the system to reset to the factory defaults.
$PNNVOJDBUJPO&SSPS - EVOLUTION
TM
encountered a communication error.
Clearing an Alert
You can clear an Alert individually or use the CLEAR ALL command to erase them all.
Step 1 – Press
HELP/SETUP.
Step 2 – Use the Up
or Down arrows to select the Alerts. Press SELECT .
Step 3 – Use the Up
or Down arrows to select individual alerts or CLEAR ALL. Press SELECT .
ALERTS
CLEAR ALL
LOW BATTERY
Step 4 – Use the Up or Down arrows to conrm (Yes) or cancel (No). Press SELECT .
Local Contact
Available only when your local distributor or dealer has programmed the local contact information in the controller.
Contact Toro
Access Contact Toro to get the latest contact information.
Step 1 – Press
HELP/SETUP.
Step 2 – Use the Up
or Down arrows to select the Alerts. Press SELECT .
CONTACT TORO
US +1(800)367-8676
TORO.COM/EVOLUTION
FOR GLOBAL SUPPORT
SEND EMAIL TO
EVOLUTION@TORO.COM
Set Time/Date
Step 1 – Press the HELP/SETUP button.
Step 2 – Use the Up
or Down arrows to navigate to SET TIME/DATE. Press SELECT .
HELP/SETUP
ALERTS
CONTACT TORO
SET TIME/DATE
LOAD FROM USB
SAVE TO USB
Step 3 – Use the Up or Down arrows to select TIME or DATE. Navigate to the TIME or DATE parameters using the
Right
arrow or SELECT .
(Continued to the next page.)

Toro EVOLUTION Series Specifications

General

Weather Sensor Compatibility	Yes
Output Voltage	24 VAC
Display	LCD
Wi-Fi Connectivity	Yes (with optional Wi-Fi module)
Mounting	Indoor/Outdoor
Maximum Load Current	0.5 amps per station
Operating Temperature	-40°C to 60°C
Enclosure Rating	NEMA 3R
Weight	Varies by model
Zones	4 to 16 (in modules of 4)
