Toro EVOLUTION Series User Manual

19
&SBTF4DIFEVMF
Use the erase schedule function to reset the selected schedule. e schedule’s status will be set to DISABLED (except for schedule A, it
remains ENABLED) and the schedule TYPE set to WEEKDAYS. All other settings within the schedule will be set to OFF.
Step 1 – While in the ADVANCED/SCHEDULE DETAILS menu, use the Up
or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 – Use the Up
or Down arrows to navigate to ERASE SCHEDULE. Press SELECT .
Step 3 – Use the Up
or Down arrows to :FT to proceed to erase the schedule or No to cancel. Press SELECT .
ERASE SCHEDULE
ARE YOU SURE? NO
4FU.71VNQ%FMBZ
Use the MV/Pump Delay function to set a wait time between activating the master valve or pump, and activating the rst zone in the
schedule. is delay is usually used to allow the system enough time to build pressure for proper operation, or to ll the irrigation piping
system with water.
Step 1 – While in the ADVANCED/SCHEDULE DETAILS menu, use the Up
or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 – Use the Up
or Down arrows to navigate to MV/PUMP DELAY. Press SELECT .
Step 3 – Use the Up
or Down arrows to adjust the delay time as necessary. Press SELECT .
SCHEDULE A
ERASE SCHEDULE
MV/PUMP DELAY 00:10
ZONE DELAY OFF
4FU;POF%FMBZ
Use the Zone Delay function to set a wait time after a zone ends watering and before another zone is activated. is delay is usually used
when the system is being fed by a well. e delay is used to allow the well enough time to recharge.
Step 1 – While in the ADVANCED/SCHEDULE DETAILS menu, use the Up
or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 – Use the Up
or Down arrows to navigate to ZONE DELAY. Press SELECT .
Step 3 – Use the Up
or Down arrows to adjust the delay time as necessary. Press SELECT .
SCHEDULE A
MV/PUMP DELAY OFF
ZONE DELAY
00:10
MV/PUMP IN DELAY OFF
4FU.71VNQ*O%FMBZ
Use the MV/Pump In Delay to set whether the master valve or pump is active during zone delays. e default is set to OFF.
Step 1 – While in the ADVANCED/SCHEDULE DETAILS menu, use the Up
or Down arrows to select the Schedule you
want to edit. Press SELECT
.
Step 2 – Use the Up
or Down arrows to navigate to MP/PUMP IN DELAY. Press SELECT .
Step 3 – Use the Up
or Down arrows to set the MP/Pump In Delay to ON or OFF during zone delays. Press SELECT .
SCHEDULE A
MV/PUMP DELAY OFF
ZONE DELAY OFF
MV/PUMP IN DELAY
ON

Toro EVOLUTION Series Specifications

General

Weather Sensor Compatibility	Yes
Output Voltage	24 VAC
Display	LCD
Wi-Fi Connectivity	Yes (with optional Wi-Fi module)
Mounting	Indoor/Outdoor
Maximum Load Current	0.5 amps per station
Operating Temperature	-40°C to 60°C
Enclosure Rating	NEMA 3R
Weight	Varies by model
Zones	4 to 16 (in modules of 4)
