ProPass 200Page 3 -- 18Hydraulic System
Working Pressure
Return
Flow
FLOOR CIRCUIT
FLOOR
MOTOR
HYDRAULIC
SPINNER
MOTORS
CONTROL
M
MANIFOLD
POWER PACK
FA FB LA LB O T1
CV1 CV2 CV3 CV4
SP1
ORF1
EC1
T
P
ORF2
ORF3
ORF4
(0.040)
(0.020)
(0.068)
(0.020)
SV1
PV1
S2 S1 S2 S1
PLUGPLUG
CONVEYOR
MOTOR
SP1 and PV1 are both energized.
Both EC1 and PV1 shift to allow proportional
flow to rear option and floor motors.
Excess and return flow will be directed to
hydraulic reservoir.
