Toro ProPass 200 Service Manual

ProPass 200Page 3 -- 32Hydraulic System
Hydraulic Control (Machines with Electronic Hydraulic Controls)
Figure 33
1. Hydraulic hose
2. Hydraulic hose
3. Hydraulic hose
4. Hydraulic control manifold
5. Hydraulic hose
6. Straight hydraulic fitting (2 used)
7. Straight hydraulic fitting (4 used)
8. Female quick disconnect
9. Male quick disconnect
10. 45
o
hydraulic fitting (2 used)
11. Tubeclamp(12used)
12. O--ring
13. Flat washer (2 used)
14. Lock washer (2 used)
15. Cap screw (3 used)
16. Cap screw (2 used)
17. O--ring
18. Seal kit
19. O--ring
20. Clamp plate (3 used)
21. Control panel guard
1
2
3
4
6
7
8
9
10
11
12
13
14
15
16
17
18
19
5
20
FRONT
RIGHT
12
12
12
12
17
17
17
17
17
18
1
6
7
7
2
3
5
21
