ProPass 200 Page 5 -- 17 Chassis
Wheel Removal (Fig. 15)
1. Position ProPass on a level surface attached to tow-
ing vehicle. Apply vehicle parking brake, stop engine
and remove key from the ignition switch. Chock Pro-
Pass wheels to prevent machine from moving.
2. Jack or hoist ProPass from ground and support ma-
chine with appropriate jack stands.
3. If removal of inner wheel assemblies is necessary,
remove walking beam a ssembly from machine (see
Walking Beam Assembly in this section).
4. Loosen and remove five (5) lug nuts from wheel to be
removed.
5. Pull wheel from walking beam assembly.
Wheel Installation (Fig. 15)
1. Position wheel to wheel hub.
2. Secure wheel to wheel hub with five (5) lug nuts.
WARNING
Failure to maintain proper lug nut torque could
result in failure or loss of wheel and may result in
personal injury.
3. Torque lug nuts in a criss--cross pattern from 70 to 90
ft--lb (95 to 122 N--m).
4. If removed, install walking beam assembly to ma-
chine (see Walking Beam Assembly in this section).
5. Carefullylowermachinetoground.
