Figure5
1.Gearshiftlever4.Hydraulicliftlock
2.Parkingbrake
5.Differentiallock
3.Hydraulicbedlift6.High–lowrangeshifter
ParkingBrake
Whenevertheengineisshutoff,theparkingbrake
(Figure5)mustbeengagedtopreventaccidental
movementofthevehicle.Toengagetheparkingbrake,
pullbackonthelever.Todisengage,pushthelever
forward.Releasetheparkingbrakebeforemovingthe
vehicle.Ifyouparkthevehicleonasteepgrade,apply
theparking.Also,shiftthetransmissioninto1stgear
onauphillgradeorreverseonadownhillgrade.Place
chocksatthedownhillsideofthewheels.
HydraulicLift
Thehydraulicliftraisesandlowersbed.Moveitrearward
toraisethebed,andforwardtolowerit(Figure5).
Important:Whenloweringthebed,holdthelever
intheforwardpositionfor1or2secondsafterthe
bedcontactstheframetosecureitinthelowered
position.Donotholdthehydraulicliftineitherthe
raiseorlowerposition,formorethan5seconds,
oncethecylindershavereachedtheendoftheir
travel.
HydraulicLiftLock
Thehydraulicliftlocklockstheliftleversothehydraulic
cylindersdonotoperatewhenthevehicleisnot
equippedwithabed(Figure5).Italsolocksthelift
leverintheOnpositionwhenusingthehydraulicsfor
attachments.
High–LowRangeShifter
Thehigh–lowrangeshifteraddsthreeadditionalspeeds
forprecisespeedcontrol(Figure5).
•Thevehiclemustbecompletelystoppedbefore
shiftingbetweenHighandLowrange.
•Shiftonlyonlevelground.
•Pressclutchpedalfully.
•MovetheleverfullyforwardforHighandfully
rearwardforLow .
Highisforhigherspeeddrivingonlevel,drysurfaces
withlightloads.
Lowisforlowspeeddriving.Usethisrangewhen
greaterthannormalpowerorcontrolisrequired.For
example,steepgrades,difcultterrain,heavyloads,slow
speedbuthighenginespeed(spraying).
Important:ThereisalocationbetweenHighand
Lowinwhichthetransaxleisinneitherrange.
Donotusethispositionasaneutralposition
becausethevehiclecouldmoveunexpectedlyif
theHigh–Lowshifterisbumpedandthegearshift
leverisingear.
IgnitionSwitch
Usetheignitionswitch(Figure6)tostartandstopthe
engine.Ithasthreepositions:Off,Run,andStart.
RotatethekeyclockwisetotheStartpositiontoengage
thestartermotor.Releasethekeywhentheenginestarts.
ThekeywillmoveautomaticallytotheOnposition.To
shuttheengineoff,rotatethekeycounterclockwiseto
theOffposition.
Figure6
1.Lightswitch6.Powerpoint
2.Choke
7.3rdhighlockoutswitch
3.Hourmeter
8.Oilpressurewarninglight
4.Fuelgauge
9.Chargeindicator
5.Ignitionswitch
HourMeter
Indicatesthetotalhoursofmachineoperation.The
hourmeter(Figure6)startstofunctionwheneverthe
keyswitchisrotatedtotheOnpositionoriftheengine
isrunning.
15
