Toro Workman HD 07369 - Additional Controls and Indicators; Switches, Warning Lights, and Gauges

3rdHighLockoutSwitch
Movethe3rdhighlockoutswitch(Figure6)totheslow
positionandremovethekeytopreventtheuseofthird
gearwhenintheHighrange.Theenginewillshutoff
iftheshiftleverismovedtothirdgearwheninHigh
range.Thekeyisremovableineitherposition.
LightSwitch
Pushthelightswitch(Figure6),totoggletheheadlights
onoroff.
OilPressureWarningLight
Theoilpressurewarninglightglows(Figure6)ifthe
engineoilpressuredropsbelowasafelevelwhilethe
engineisrunning.Ifthelightickersorremainson,
stopthevehicle,turnofftheengine,andchecktheoil
level.Iftheoillevelwaslow,butaddingoildoesnot
causethelighttogooutwhentheengineisrestarted,
turntheengineoffimmediatelyandcontactyourlocal
Torodistributorforassistance.
Checktheoperationofwarninglightsasfollows:
1.Applytheparkingbrake.
2.TurntheignitionkeytotheOnposition,butdonot
starttheengine.Theoilpressurelightshouldglow
red.Ifthelightdoesnotfunction,eitherabulbis
burnedoutorthereisamalfunctioninthesystem
whichmustberepaired.
Note:Ifenginewasjustturnedoff,itmaytake1to2
minutesforthelighttocomeon.
ChargeIndicator
Illuminateswhenthebatteryisbeingdischarged.Ifthe
lightilluminatesduringoperation,stopthevehicle,turn
offtheengineandcheckforpossiblecauses(Figure6).
Checktheoperationofwarninglightsasfollows:
•Applytheparkingbrake.
•TurntheignitionkeytotheOnposition,butdo
notstarttheengine.Thechargeindicatorandoil
pressurelightsshouldglow .Ifanylightdoesnot
function,eitherabulbisburnedoutorthereisa
malfunctioninthesystemwhichmustberepaired.
FuelGauge
Thefuelgaugeshowstheamountoffuelinthetank.It
operatesonlywhenignitionswitchisintheOnposition
(Figure6).Redindicateslowfuellevelandblinkingred
indicatesnearempty.
PowerPoint
Usethepowerpoint(Figure6)topoweroptional12
voltelectricalaccessories.
Choke
Tostartacoldengine,closethecarburetorchokeby
pullingthechokecontrol(Figure6)outtotheOn
position.Aftertheenginestarts,regulatethechoketo
keeptheenginerunningsmoothly.Assoonaspossible,
openthechokebypushinginthechokecontrolto
theOffposition.Awarmenginerequireslittleorno
choking.
PassengerHandHold
Thepassengerhandholdislocatedonthedashboard
(Figure7).
Figure7
1.Passengerhandhold
2.Storagecompartment
SeatAdjustingLever
Theseatscanbeadjustedforeandaftforoperator
comfort(Figure8).
16
