HeavyDutyOperation
Important:Ifthevehicleissubjectedtoanyoftheconditionslistedbelow,maintenanceshouldbe
performedtwiceasfrequently:
•Desertoperation
•Coldclimateoperationbelow32degreesF(0degreesC)
•Trailertowing
•Frequentoperationondustyroads
•Constructionwork
•Afterextendedoperationinmud,sand,water,orsimilardirtyconditions,haveyourbrakesinspectedandcleaned
assoonaspossible.Thiswillpreventanyabrasivematerialfromcausingexcessivewear.
Premaintenance
Procedures
Manyofthesubjectscoveredinthismaintenancesection
requireraisingandloweringthebed.Thefollowing
precautionsmustbetakenorseriousinjuryordeath
couldresult.
Beforeservicingormakingadjustmentsto
themachine,stopengine,setparkingbrake,
andremovekeyfromtheignitionswitch.
Removeanyloadmaterialfromthebedor
otherattachmentbeforeworkingundera
raisedbed.Neverworkunderaraisedbed
withoutpositioningthesafetysupportonafully
extendedcylinderrod.
UsingtheBedSafetySupport
Important:Alwaysinstallorremovethebed
supportfromtheoutsideofthebed.
1.Raisethebeduntiltheliftcylindersarefully
extended.
2.Removethebedsupportfromthestoragebrackets
onbackoftheROPSpanel(Figure23).
Figure23
1.Bedsupport
3.Pushthebedsupportontothecylinderrod,making
surethesupportendtabsrestontheendofcylinder
barrelandonthecylinderrodend(Figure24).
Figure24
1.Bedsupport3.Bed
2.Cylinderbarrel
4.Whennished,removethebedsupportfromthe
cylinderandinsertitintothebracketsontheback
oftheROPSpanel.
32
