EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Every50hours—Cleanandoilthe
aircleanerfoampre-cleaner.(Every
25hoursifoperatingconditionsare
extremelydustyorsandy)
Every50hours—Inspecttheair
cleanerpaperelement.
Every200hours
1.Removetheknob,O-ring,andcover(Figure35).
Figure35
1.KnobandO-ring
5.Breatherseal
2.Aircleanercover6.Foampre-cleaner
3.Wingnut7.Paperelement
4.Innercover
2.Removethefoampre-cleanerbyslidingitoffofthe
paperelement,andcleanitasfollows:
A.Washthefoampre-cleanerindetergentand
warmwater.
B.Wrapthefoampre-cleanerinclothandpressdry.
Donotwringthepre-cleaner.Allowittoairdry.
C.Saturatethefoampre-cleanerincleanengineoil.
Pressittoremoveanyexcessoil.
3.Installthefoampre-cleanerontothepaperelement.
Donotwashthepaperelementorcleanitwith
compressedair,asdamagewilloccur.
Note:Withtheaircleanerdisassembled,checkthe
aircleanercomponentsfordamage.Replaceand
damagedparts.
4.Installtheelementwiththepre-cleaner,breather
seal,innercover,wingnut,aircleanercover,O-ring,
andknob.
5.Tightentheknob1/2to1turnafterknobcontacts
thecover.Donotovertighten.
ChangingtheEngineOilAnd
Filter
ServiceInterval:Aftertherst50hours
Every100hours
1.Raisethebed(ifsoequipped)andplacethesafety
supportontheextendedliftcylindertoholdupthe
bed.
2.Removethedrainplugandletoilowintoadrain
pan(Figure36).Whentheoilstops,installthedrain
plug.
Figure36
1.Engineoildrainplug
2.Engineoillter
3.Removetheoillter(Figure36).
4.Applyalightcoatofcleanoiltothenewlterseal
beforescrewingiton.
5.Screwthelteronuntilthegasketcontactsthe
mountingplate,thentightenthelter1/2to2/3of
aturn.Donotovertighten.
6.Addoiltothecrankcase;refertoCheckingthe
EngineOilLevel.
