CoolingSystem
Maintenance
RemovingDebrisfromthe
EngineCoolingSystem
ServiceInterval:Every100hours(Cleanmore
frequentlyindirtyconditions.)
Toensurepropercooling,cleantheblowerhousingand
othercoolingshroudsandcleanthecoolingnsand
externalsurfaces.
Note:Operatingtheenginewithdirtyorplugged
coolingnsorwiththecoolingshroudsremoved,will
causeenginedamageduetooverheating.
BrakeMaintenance
AdjustingtheParkingBrake
ServiceInterval:Aftertherst10hours
Every200hours
1.Removetherubbergripfromtheparkingbrakelever
(Figure49).
Figure49
1.Parkingbrakelever
2.Grip
2.Loosenthesetscrewsecuringtheknobtothe
parkingbrakelever(Figure50).
3.Rotatetheknobuntilaforceof45to50lb(20to22
kg)isrequiredtoactuatethelever.
Figure50
1.Parkingbrakelever
3.Setscrew
2.Knob
4.Tightenthesetscrewwhennished.
Note:Ifnoadjustmentisleftatthehandle,loosen
thehandletothemiddleoftheadjustmentand
adjustthecableattherear,thenrepeatstep3.
5.Installtherubbergripontotheparkingbrakelever.
43
