28.Securethe4seatbackstotheseatpanelsusing
12hex-washerheadbolts(1/4x3/4inch)as
showninFigure55.
Torquethe12hex-washerheadbolts(1/4x3/4
inch)to5.4N∙m(48in-lb).
g364846
Figure55
29.Installthepreviouslyremovedlocknuts(3/8
inch)andlatchpinstotherightandleft,rear
frametubes(Figure56).
g364832
Figure56
