Toro Workman UTX - Drive System Controls

2-WheelDrive/4-Wheel
Drive/DifferentialLockIndicator
Note:Whentheindicator(Figure62)isblinkingit
meansthatthesettingisnotengaged/inactive;when
itbecomessolid,itisengaged/active.
RefertoFigure63andthecorrespondingtablefor
usingthe2-wheeldrive/4-wheeldriveswitchand
differentiallockswitchtogether.
g388483
Figure63
1.Upposition—engages
4-wheeldrive
4.Midposition—engagesthe
reardifferentiallockonly
2.Downposition—engages
2-wheeldrive
5.Down
position—disengages
thedifferentiallock(s)
3.Upposition—engages
boththefrontandrear
differentiallocks
2-Wheel
Drive/4-Wheel
DriveSwitch
Position
DifferentialLock
SwitchPosition
Result
2
5
Noindicator
24
23
(blinking—inactive
conguration)
1
5
14
13
CruiseControl/Speed-Limited
Indicator
Ifthecruisecontrolisset,theindicatorilluminates
(Figure62).
Ifthetopspeedofthemachineislimited,theindicator
illuminates.Thespeedislimitedifthefollowing
occurs:
•Thecruisecontrolisset.
•Thereisafaultcode.
•Aseatbeltisnotbuckled.
HeadlightsIndicator
Theheadlightsindicatorilluminateswhenthe
headlightsareintheONposition.
SeatBeltIndicator
Theseatbeltindicatorilluminateswhentheoperator
doesnothavetheirseatbeltfastened.
Note:Iftheseatbeltisnotfastened,themachine
speedwillbelimited.
FaultCodeIndicator
Thefaultcodeindicatorilluminatesandthe
correspondingfaultcodenumberappearswhena
machinefaultoccurs.
