AcceleratorPedal

Usetheacceleratorpedal(Figure64)tovarythe

groundspeedofthemachinewhenthetransmission

isingear.Pressingdowntheacceleratorpedal

increasestheenginespeedandgroundspeed.

Releasingthepedaldecreasestheenginespeedand

groundspeed.

g356337

Figure64

1.Brakepedal2.Acceleratorpedal

BrakePedal

Usethebrakepedaltostoporslowthemachine

(Figure64).

CAUTION

Operatingamachinewithwornor

incorrectly-bledbrakesmayresultinpersonal

injury.

Ifthebrakepedaltravelstowithin25mm(1

inch)ofthemachineoorboard,bleedand/or

repairthebrakes.
