Toshiba B-SA4T User Manual

- 17 -
2.2 Installation under Windows 2000/XP/Server2003
Note: Proper operation is not guaranteed on the PC running Windows 2000.
1. Turn on the PC.
Note: Log on as the user with administrative privilege.
2. Select the “Start”, “Printer and FAX” to show the printer folder.
Supplement: In the case of Windows 2000, select “Start”, “Setting”, and “Printer”. If the “Printer and FAX” folder
is not found, click the “Control Panel” and select the “Printer and FAX”.
In the case of the category view, click the “Printer and Other Hardware” and select the “Printer and
FAX”.
3. Select the “Add printer” from the File menu. The “Add Printer Wizard” is displayed.
4. Click the [Next] button in the “Add Printer Wizard”.
5. Select the “Local printer attached to this
computer” and click the [Next] button.
Note: Do not check the “Automatically detect and
install my Plug and Play printer” checkbox.
Even in the case of specifying the network printer
or a printer connected to other PC, be sure to
choose the local printer in this step. This setting
is changed after the installation is completed.
(To print on the shared printer.)

Toshiba B-SA4T Specifications

General

Print Method	Thermal transfer and direct thermal
Resolution	203 dpi
Print Width	104 mm
Interfaces	Serial, Parallel, USB
Optional Interfaces	Ethernet, Wireless
Barcodes	Code 39, Code 128
2D Codes	PDF417, Data Matrix, QR Code, MaxiCode
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20 - 60 °C (-4 - 140 °F)
Humidity	20% to 85% (non-condensing)
Interface	USB, Serial (RS-232), Parallel, Ethernet, Wireless
