Toshiba B-SA4T User Manual

- 24 -
2.3 Installation under Windows Vista/Server2008/7/
Server2008R2/8/Server2012/Server2012R2/10
Note: If the installation did not succeed, follow the procedure described in How to set up Windows
Vista/Server2008/7/Server2008R2/8/Server2012/Server2012R2/10 again.
1. Turn on the PC.
Note: Log on as the user with administrative privilege.
2. Select “Start”, “Control Panel”, “Hardware and Sound”,
and “Printer” to open the printer folder.
Supplement: Entering “Printer” in the Search box of the Start menu causes the “Printer” to be shown in the
Program.
3. Click the “Install a Printer” to start adding a printer.
4. Select the “Add a local printer”.
5. Select a printer port, and click the [Next] button.

Toshiba B-SA4T Specifications

General

Print Method	Thermal transfer and direct thermal
Resolution	203 dpi
Print Width	104 mm
Interfaces	Serial, Parallel, USB
Optional Interfaces	Ethernet, Wireless
Barcodes	Code 39, Code 128
2D Codes	PDF417, Data Matrix, QR Code, MaxiCode
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20 - 60 °C (-4 - 140 °F)
Humidity	20% to 85% (non-condensing)
Interface	USB, Serial (RS-232), Parallel, Ethernet, Wireless
