Toshiba B-SA4T User Manual

- 92 -
4. System Configuration
The system requirements for this printer driver are as follows:
Computer
IBM PC-AT compatible
Windows
NT
Microsoft Windows 2000/XP/Server 2003/Vista/Server 2008/7/Server 2008 R2 / 8 / Server2012 /
Server2012R2 / 10
Windows
9X
Microsoft Windows 98/Me
Printer
TOSHIBA TEC Bar Code Printer
Centronics
Centronics interface cable
Printer
server
Connection method to Ethernet
B-SV4: Optional LAN adapter
B-SX: Optional PCMCIA board and LAN card
B-SX: Optional LAN board
B-SA4/B-852-R/B-452-R/B-EP2/B-EP4/B-EV4/B-SX6T/8T/B-EX4T1/T2/B-462-R/B-FP/B-EX6T1/
B-EX6T3/B-EX4T3:
The LAN interface is provided as standard.
Notes:
1. When the printer server is used, set the port by following the guideline of the printer server device.
2. When the Toshiba TEC optional LAN board or a set of the optional PCMCIA board and a LAN card is used to
connect the printer to the LAN, refer to Section 6.3 How to Connect the Printer to LAN.
3. When the printer is used as the network printer, refer to To print on the shared printer described in the
installation procedure by OS.

Toshiba B-SA4T Specifications

General

Print Method	Thermal transfer and direct thermal
Resolution	203 dpi
Print Width	104 mm
Interfaces	Serial, Parallel, USB
Optional Interfaces	Ethernet, Wireless
Barcodes	Code 39, Code 128
2D Codes	PDF417, Data Matrix, QR Code, MaxiCode
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20 - 60 °C (-4 - 140 °F)
Humidity	20% to 85% (non-condensing)
Interface	USB, Serial (RS-232), Parallel, Ethernet, Wireless
