Toshiba B-SA4T User Manual

- 61 -
3.1.3 Advanced Options
Clicking the [Advanced Options] button allows control of the printer options for which the printer driver does not
provide explicit control.
 Printing Position
 Position Adjustment tab
 Horizontal Offset
Enables adjustment of the print position in the
horizontal direction.
Since this feature is not supported, do not change
the default setting.
 Vertical offset
Enables adjustment of the print position in the
vertical direction.
Since this feature is not supported, do not change
the default setting.
 Orientation Adjustment
 Default Orientation
Enables specifying the default orientation.
0º: Bottom first
180º: Top first
Since this feature is not supported, do not change the default setting.
 User Commands tab
You can program printer command strings which
are to be sent to the printer at “Start of Job”, “Start
of Label”, “End of Label” or “End of Job” to make up
for the functions that cannot be covered by this
printer driver.
Supplement: For details of the commands, please
refer to the External Equipment Interface
Specification.

Toshiba B-SA4T Specifications

General

Print Method	Thermal transfer and direct thermal
Resolution	203 dpi
Print Width	104 mm
Interfaces	Serial, Parallel, USB
Optional Interfaces	Ethernet, Wireless
Barcodes	Code 39, Code 128
2D Codes	PDF417, Data Matrix, QR Code, MaxiCode
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20 - 60 °C (-4 - 140 °F)
Humidity	20% to 85% (non-condensing)
Interface	USB, Serial (RS-232), Parallel, Ethernet, Wireless
