Toshiba B-SA4T User Manual

- 95 -
5. Addition/Deletion of Standard TCP/IP Port
When connecting the printer via LAN interface, configure the following settings on the printer using the printer
system mode menu <7>IP ADDRESS.
• PRINTER IP ADDRESS
• GATEWAY IP ADDRESS
• SUBNET MASK
• SOCKET PORT
The above PRINTER IP ADDRESS and SOCKET PORT are used as the “Printer Name or IP address” and “Port
No.”, respectively when adding a port.
Note: When the “Bi-directional support” is used, do not specify the same output port for the multiple printer drivers on a
computer. When you want to specify the same output port for the multiple printer drivers, disable the [Printer Status
Monitoring].
Also, when multiple computers connect to the same printer, specify that printer as the shared printer or disable the
[Printer Status Monitoring].

Toshiba B-SA4T Specifications

General

Print Method	Thermal transfer and direct thermal
Resolution	203 dpi
Print Width	104 mm
Interfaces	Serial, Parallel, USB
Optional Interfaces	Ethernet, Wireless
Barcodes	Code 39, Code 128
2D Codes	PDF417, Data Matrix, QR Code, MaxiCode
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20 - 60 °C (-4 - 140 °F)
Humidity	20% to 85% (non-condensing)
Interface	USB, Serial (RS-232), Parallel, Ethernet, Wireless
