4 Replacement Procedures
FRU. After you determine those FRUs, go to the appropriate sections according to the section
numbers shown in the boxes. Then start removal and replacement.
4.2 Battery 4.3 HDD 4.4 Memory
4.5 Keyboard
4.6 TV Tuner
Card and WLAN
4.7 ODD module
(Tray-load)
4.8 Logic Upper
Assembly
4.10 FeliCa Card
4.12 Touch Pad Board
4.13 Speakers and
Speaker Cushions
4.9 ODD module
(Slot-load)
4.14 Indicator
Board
4.15 USB Board
4.16 Bluetooth
4.18 TV Tuner
Antenna
4.19 Power
Membrane
4.20 Display Assembly
4.11 Fingerprint
Scanner Bracket
4.22 Thermal
Module
4.24 LCD Bezel
4.17 Thermal Fan
4.25 LCD Panel
4.26 Web Camera
4.23 CPU
4.27 WLAN Antennas
4.28 LCD Panel Hinges
4.29 LVDS Cable
4.21 Motherboard
Assembly
How to use the chart (two
examples):
• For removing the Motheroard:
First, remove parts from 4.8
Keyboard Cover & Keyboard,
4.9 Logic Upper Assembly,
4.16 WLAN card, 4.15
Thermal Fan.
• For removing the LCD
Module:
First, remove 4.21 LCD Bezel
Assembly, then remove 4.22
the LCD module and the
Inverter Board.
Satellite A660/ProA660 Series Maintenance Manual 4-2
4.2 Battery
4.3 HDD 4.4 Memory
4.10 FeliCa Card
4.5 Keyboard
4.6 TV Tuner
Card and WLAN
4.7 ODD module
(Tray-load)
4.8 Logic Upper
Assembly
4.11 Fingerprint
Scanner Bracket
4.12 Touch Pad Board
4.13 Speakers and
Speaker Cushions
4.9 ODD module
(Slot-load)
4.15 USB Board
4.14 Indicator
Board
4.18 TV Tuner
Antenna
4.16 Bluetooth
4.24 LCD Bezel
4.17 Thermal Fan
4.25 LCD Panel
4.19 Power
Membrane
4.20 Display Assembly
4.26 Web Camera
4.27 WLAN Antennas
4.21 Motherboard
Assembly
4.22 Thermal
Module
4.23 CPU
4.28 LCD Panel Hinges
4.29 LVDS Cable
To Next Page
