Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
Removing the WLAN Card
Remove the WLAN card according to the following procedures and Figure 4.14.
1. Disconnect the two antennas on the WLAN card.
2. Remove one M2.5x5 screw securing the WLAN card as shown in Figure 4.14.
3. Pull the WLAN card out at an angle.
M2.5x5*1
Figure 4.14 Removing the WLAN Card
Installing the TV Tuner Card
Install the TV tuner card according to the following procedures.
1. Insert the TV tuner card into the connector as shown in Figure 4.13.
2. Press the TV tuner card down and secure it with one M2.5x5 screw.
3. Attach the antenna to the TV tuner card.
Satellite A660/ProA660 Series Maintenance Manual 4-21

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
