Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
4.13 Speakers and Speaker Cushions
Removing the Speakers
Remove the speakers according to the following procedures and Figure 4.27.
1. Pull the FCC cable covering the speaker cables from the slot as indicated in Figure 4.27.
2. Pull the speaker cables from the routing channel.
3. Remove the four M2.5x6.5 screws securing the speakers to the logic upper assembly and
remove the speakers.
M2.5x6.5*2
M2.5x6.5*2
Figure 4.27 Removing the speakers
Satellite A660/ProA660 Series Maintenance Manual 4-37

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
