Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
4.14 Indicator Board
Removing the Indicator Board
Remove the indicator board according to the following procedures and Figure 4.29.
1. Disconnect the indicator board cable from the motherboard.
2. Lift the indicator board out of the slot and remove it.
Figure 4.29 Removing the indicator board
Installing the Indicator Board
Install the indicator board according to the following procedures.
1. Place the indicator board in the slot and attach the cable to the motherboard as shown in
Figure 4.29.
Satellite A660/ProA660 Series Maintenance Manual 4-39

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
