Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
2. Use your fingers to push the HDD in the direction indicated by the arrows in Figure 4.3.
Figure 4.3 Releasing the HDD from the connector
3. Pull the tab and remove the HDD as shown in Figure 4.4.
Figure 4.4 Removing the HDD from the HDD bay
NOTE: Do not disassemble the HDD pack when it is working normally. Disassemble or
replace the HDD pack only if it fails.
4. Place the HDD pack on a flat surface such as a desk.
Satellite A660/ProA660 Series Maintenance Manual 4-12

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
